Technical Specifications
Dimensions and Weight
Weight 103 Kg (227 Ib)
Length without shank adapter 826 mm Length with shank adapter 996 – 1,007 mm Overall Width 314 mm (12.3 inch)
Height 164.5 mm (6.4 inch) Rotation Specs
Max. Rotation Speed (RPM) 31cc (235 rpm), 43cc (209 rpm), 55cc (193 rpm), 67cc (237 rpm) Oil Flow (I / min) 31cc (25 I / min), 43cc (30 I / min), 55cc (35 I / min), 67cc (52 I / min)
Max. Pressure (bar) 31cc (140 bar), 43cc (140 bar), 55cc (140 bar), 67cc (140 bar) Max. Torque (Nm) 31cc (230 Nm), 43cc (305 Nm), 55cc (385 Nm), 67cc (466 Nm) Impact Ratings
Max. Output 12 – 14 kW (16 – 19 hp)
Input Range 21 – 23 kW (28.5 – 31 hp) Percussion Flow Range (Max.) 90 – 105 I / min
Percussion Pressure Range 130 – 150 bar (1885 – 2175 psi)
Max. Impact Frequency 55 – 70 Hz (3300 – 4200 bpm) Flushing Flow and Pressure
Water Flushing 30 – 60 I / min
Front end Lubricating air Consumption 300 I / min
Shank Adapters
D45 H25 F 86761533
D45 R32 F 866638087
D38 R32 M 86619400
D38 R38 M 86619558
D38 T38 M 86619566
Category: Machinery
Sub-Category: Mining Machinery
Technical Specifications
Dimensions and Weight Weight 175 Kg (386 Ib)
Length without shank adapter 1008 mm (3 ft 3.6 inch Width including connectors 251 mm (9.9 inch)
Height 223 mm (8.8 inch)
Rotation Ratings
Rotation range 0 – 340 rpm, 0 – 275 rpm, 0 – 215 rpm
Torque (maximum) 640 Nm (472 Ibf-ft), 850 Nm (605 Ibf-ft), 1000 Nm (737 Ibf-ft) Working pressure (maximum) 210 bar (3046 psi)
Oil consumption 75 I/ min (2.6 cfm)
Impact Ratings
Impact power (maximum) 18 kW (24 hp) Input power to rock drill (maximum) 31 kW (41.6 psi) Hydraulic pressure (maximum) 230 bar (3336 psi)
Flow rate 75 – 92 I/min (2.5 – 3 cfm) Impact frequency 60 Hz
Flushing Flow and Pressure
Flushing water pressure (maximum) 25 bar (363 psi) Lubricating air consumption at 2 bar (29 psi) 5 I/s (10.6 cfm)
Flushing water consumption 55 – 120 I/s (2 – 4.3 cfm)
Service Kits Seal kit 3115 9170 91
Shank Adapter R32 403 – 09101,10
R38 404 – 09101,10
T38 435 – 09101,10
Magnum SR38 427 – 09101,10
Category: Machinery
Sub-Category: Mining Machinery
Technical Specifications
Impact Ratings Power class 33 kW
Percussion rate 30-40 Hz Hole diameter 89-127-152 mm
Operating pressure Percussion 90-200 bar Rotation (max.) 200 bar
Rotation motor type Motor type – OMT 400, OMT 500
Shanks
65 mm T51 / ST58 / GT60-760
80 mm GT60-760
80 mm ST68-630
80 mm ST58 / ST68-635
Weight
470 – 490 kg
Category: Machinery
Sub-Category: Mining Machinery
Shank adapter: R32, R38, T38, or T45
Material: Carbon steel Weight: 3.9–6.0 kg
Applications: Bench drilling, construction, drifting, and tunneling
Category: Machinery
Sub-Category: Mining Machinery
Technical Specifications
Impact Ratings Power class 19,5 kW
Percussion rate 45-52 Hz
Hole diameter drilling 65-115mm
Operating pressure Percussion
100 – 190 bar Rotation (max.) 200 bar
Rotation motor type
Motor type
OMT 200, OMT 250 or OMT 315
Shanks
38 mm rod T38 / 600
45 mm rod T45 / 600
51 mm rod T51 / 600 Weight
245 – 300 kg
Category: Machinery
Sub-Category: Mining Machinery
Hole diameter drilling
43 – 64 mm
Hole diameter reaming 76 – 127 mm
Power class 20 kW
Percussion rate 67 Hz
Operating pressure Percussion Rotation (max.) 120 – 220 bar
175 bar Rotation motor type
OMS 80, OMS 125 or OMS 160
Drill steels
R32, R39 or Hex 35 mm drifter rods, MF-rods highly recommended Shanks
45 mm / T38 / R32 / T35 / R38 / T45
Weight 210 kg
Category: Machinery
Sub-Category: Mining Machinery
Shank
Hole diameter 33 mm – 64 mm
Power Rating 20 kW
Application For underground Applications
Input System Hydraulic
Category: Machinery
Sub-Category: Mining Machinery
Technical Specifications
Impact Ratings Power class
14 kW
Percussion rate 110 Hz
Hole diameter bolting 33-43mm
Operating pressure Percussion
120 – 180 bar Percussion (drilling) 120 – 180 bar Rotation (max.) 175 bar
Rotation motor type Motor type
OMS 100 ve OMS 125 Shanks R32 -T38 – T35
Weight -127 kg
Category: Machinery
Sub-Category: Mining Machinery
SC-85D Mobile VSI Sand Making Machine is a crawler-mounted vertical shaft sand making unit that utilizes a high-speed impact crushing mechanism to process various materials into fine aggregates.
Category: Machinery
Sub-Category: Mining Machinery
SE-1060 tracked jaw crusher is engineered for primary crushing in demanding applications. It performs effectively across a wide range of materials including soft rock, construction waste, concrete blocks, and hard rock. Its tracked design allows it to navigate complex terrain, making it especially suitable for mobile operations in mining sites, urban demolition zones, road and bridge construction, and aggregate production yards.
Category: Machinery
Sub-Category: Mining Machinery
SE-1160 Heavy Duty Mobile Jaw Crusher is ideally suited for large-scale material handling and first-stage crushing in harsh environments. It performs exceptionally well with tough materials such as hard rock, large granite blocks, iron ore, and construction demolition debris. Its tracked mobility enables flexible movement across rugged terrain, making it suitable for remote mining operations, large quarry sites, and high-volume infrastructure projects.
Category: Machinery
Sub-Category: Mining Machinery
Suhman SE-650D versatile mini mobile jaw crusher operates using a mechanical compression process tailored for small to medium-scale crushing needs. It features a compact jaw crushing unit mounted on a fully mobile tracked chassis. When materials are fed into the chamber, the eccentric shaft drives the moving jaw in a dynamic arc toward the fixed jaw, applying compressive force to break the material into smaller sizes.
Category: Machinery
Sub-Category: Mining Machinery
Self-centering vibrating screen
Category: Machinery
Sub-Category: Mining Machinery
SF-380D Mobile Impact Crusher is a crawler-mounted mobile impact crusher designed for efficient on-site crushing.
Category: Machinery
Sub-Category: Mining Machinery
SF-580D Heavy Duty Mobile Impact Crusher is a high-capacity, heavy-duty crawler-type mobile impact crusher designed to handle tough materials such as reinforced concrete, construction debris, and natural stone.
Category: Machinery
Sub-Category: Mining Machinery
SF-580D-S Mobile Impact Crushing and Screening Unit is a fully integrated crawler-type mobile unit that combines both crushing and screening functions in a single, compact system. It is designed to efficiently process construction waste and natural stone on-site, reducing the need for additional equipment and maximizing operational efficiency.
Category: Machinery
Sub-Category: Mining Machinery
Spiral classifier with non-immersed spiral
Category: Machinery
Sub-Category: Mining Machinery
SS‑7018 Mobile Inclined Vibrating Screening Plant is equipped with an inclined, multi-deck vibrating screen powered by vibration motors or eccentric blocks.
Category: Machinery
Sub-Category: Mining Machinery
SSP‑6200 Mobile Horizontal Screening Plant is a crawler-mounted, horizontal scalping screen built for large-volume and sticky material processing.
Category: Machinery
Sub-Category: Mining Machinery
SY‑HP200 Mini Mobile Cone Crusher is a compact, hydraulically powered cone crusher mounted on crawler tracks. The entire unit—crusher, hydraulic systems, and conveyors—is integrated, enabling fast deployment and reliable performance. The SY‑HP200 is ideal for secondary or tertiary crushing in small- to medium-scale operations.
