FL57STH
Category
Sub-Category
Completed orders
Price
Delivery Cost
Minimum Order
Location
General specification
Item | Specifications |
Step Angle | 0.9° |
Step Angle Accuracy | ±5% (full step, no load) |
Radial Play | 0.02mm@450g |
Axial Play | 0.08mm@450g |
Maximum radial force | 75N 20mm from the flange |
Max. axial force | 15N |
Dielectric Strength | 600VAC/1S |
Insulation Resistance | 100MΩ ,500VDC |
Ambient Temperature | -20℃~+50℃ |
Insulation Class | Class B |
Electrical specifications
Model No. | Current /Phase Each phase Current | Resistance /Phase Each phase resistance | Inductance /Phase Each phase inductance | Holding Torque Keep Torque | Detent Torque position Torque | # of Leads Number of leads | Rotor Inertia Moment of Inertia | Weight weight | Length body length |
Single shaft (Single output shaft) | A | Ω | mh | Nm | Nm | # | g-cm2 | kg | mm |
FL57STH41-2006MA | 2.0 | 1.4 | 2.2 | 0.39 | 0.021 | 6 | 120 | 0.45 | 41 |
FL57STH41-2804MA | 2.8 | 0.7 | 2.2 | 0.55 | 0.021 | 4 | 120 | 0.45 | 41 |
FL57STH56-2006MA | 2.0 | 1.8 | 4.5 | 0.9 | 0.04 | 6 | 300 | 0.7 | 56 |
FL57STH56-2804MA | 2.8 | 0.9 | 4.5 | 1.2 | 0.04 | 4 | 300 | 0.7 | 56 |
FL57STH76-2006MA | 2.0 | 2.25 | 5.6 | 1.35 | 0.068 | 6 | 480 | 1.0 | 76 |
FL57STH76-2804MA | 2.8 | 1.13 | 5.6 | 1.8 | 0.068 | 4 | 480 | 1.0 | 76 |
This motor can be customized according to customer needs.
The motor can be designed &manufactured with customized request.
