PRODUCT | RANK NO. | NOMINAL | SIZE | POWER | VOLTAGE | FLUX | EFFECT | BASE | PART NUMBER |
(CCT/k) | (mm) | (W) | (VF/V) | (lm) | (LM/W) | ||||
B1702WVD1 | B101 | 3000K | 17*47 | 0.2 | 12 | 18 | 90 | E14 | 9405500000B101 |
B1702WTD1 | B102 | 4000K | 17*47 | 0.2 | 12 | 18 | 90 | E14 | 9405500000B102 |
B1702WPD1 | B103 | 6000K | 17*47 | 0.2 | 12 | 18 | 90 | E14 | 9405500000B103 |
B1702WVD2 | B101 | 3000K | 17*47 | 0.2 | 24 | 18 | 90 | E14 | 9405500000B104 |
B1702WTD1 | B102 | 4000K | 17*47 | 0.2 | 24 | 18 | 90 | E14 | 9405500000B105 |
B1702WPD2 | B103 | 6000K | 17*47 | 0.2 | 24 | 18 | 90 | E14 | 9405500000B106 |
B1702BD1 | B104 | 460 | 17*47 | 0.2 | 12 | 5 | 25 | E14 | 9405500000B107 |
B1702GD1 | B105 | 520 | 17*47 | 0.2 | 12 | 20 | 90 | E14 | 9405500000B108 |
B1702YD1 | B106 | 585 | 17*47 | 0.15 | 12 | 7 | 30 | E14 | 9405500000B109 |
B1702OD1 | B107 | 605 | 17*47 | 0.15 | 12 | 7 | 25 | E14 | 9405500000B110 |
B1702RD1 | B108 | 620 | 17*47 | 0.15 | 12 | 9 | 30 | E14 | 9405500000B111 |
B1702BD2 | B109 | 460 | 17*47 | 0.2 | 24 | 5 | 25 | E14 | 9405500000B112 |
B1702GD2 | B110 | 520 | 17*47 | 0.2 | 24 | 20 | 90 | E14 | 9405500000B113 |
B1702YD2 | B111 | 585 | 17*47 | 0.15 | 24 | 7 | 30 | E14 | 9405500000B114 |
B1702OD2 | B112 | 605 | 17*47 | 0.15 | 24 | 7 | 25 | E14 | 9405500000B115 |
B1702RD2 | B113 | 620 | 17*47 | 0.15 | 24 | 9 | 30 | E14 | 9405500000B116 |
