WEET WMO 0.01uF 103J 630V Copper Foil and PP in Oil Capacitors for Crossover
Category
Sub-Category
Completed orders
Price
Delivery Cost
Minimum Order
Location
If you need special price or discount for a bunch of capacitors, please check our company official website and then contact with us by email, thank you. We are more than pleased to provide better offer if you would like to share the test review with us. Thank you.
info@weetcap.com
Whatsapp: +86 176 7621 4359
Name:WEET WMO Oil Immersed Pure Copper Foil and PP Polypropylene Film Capacitors
Typical application: Crossover, Tweeter Bass, Audio Speaker, CD player, Amplifier, Loudspeakers, DAC Built, Crossover Filters, Middle range speaker.Bravery amplifier.Home audio, car audio, stage audio and other audio equipment.
Cross Reference:WEET WMO Oil Immersed Pure Copper Foil and PP Polypropylene Film Capacitors Cross Miflex KPCU Copper Foil Capacitor, Duelund JDM series copper foil oil immersed Capacitor, Audyn True Copper Foil Capacitor, Audionote Copper Foil in Oil Capacitor,Jensen copper foil capacitors, Jupiter copper foil capacitor
Manufacturing Background Customer Testimonials:
A:The WMO caps have fast, uncolored sound, full of life, dense body, wide sound stage, natural organic voices etc.
B:The elaboration has become noticeably deeper, there are moments in familiar recordings that I hadn't heard before. WMO reveals the speaker's capabilities much better.
About WEE Technology
WEET with the help of world-class audio manufacturers, it has entered the electroacoustic field of Hi-Fi high quality audio capacitors. With the efforts of 40 years, it has become a world-class audio capacitor OEM factory, and has developed various high quality products with special processes for major audio manufacturers. WEE are Capacitors Specialist.
Structure
Imported 6N copper foil inner core.
High tin content tin zinc alloy welding layer.
PET metal coating, flame retardant epoxy resin encapsulation.
Silver plated copper wire.
Technology
German high-temperature industrial oil impregnation technology.
High temperature vacuum heat treatment technology.
Independently develops the "13 layer" gold spraying technology.
Features
Extremely low loss, internal resistance, and inductance.
Stable operation with a lifespan of 100000 hours and unchanged sound quality.
The outer sealing material has a shielding effect.
| (Unit：μF) | (×10 -4) | OD | L | d | Lead Length |
| Capacitance | Dissipation Factor | ±2mm | ±2mm | ±0.05mm | ±0.05mm |
| 630VDC | |||||
| 0.01 | 3 | 11.5 | 21 | 1.0Ag-Cu | 40/50 |
| 0.012 | 3 | 12 | 21 | 1.0Ag-Cu | 40/50 |
| 0.015 | 3 | 13 | 21 | 1.0Ag-Cu | 40/50 |
| 0.018 | 3 | 14 | 21 | 1.0Ag-Cu | 40/50 |
| 0.022 | 3 | 15 | 21 | 1.0Ag-Cu | 40/50 |
| 0.033 | 3 | 17 | 21 | 1.0Ag-Cu | 40/50 |
| 0.047 | 3 | 20 | 21 | 1.0Ag-Cu | 40/50 |
| 0.068 | 3 | 24 | 21 | 1.0Ag-Cu | 40/50 |
| 0.1 | 3 | 25 | 21 | 1.0Ag-Cu | 40/50 |
| 0.22 | 3 | 22 | 36 | 1.0Ag-Cu | 40/50 |
| 0.33 | 3 | 20 | 58 | 1.0Ag-Cu | 40/50 |
| 0.47 | 3 | 23 | 58 | 1.0Ag-Cu | 40/50 |
| 0.56 | 5 | 26 | 58 | 1.0Ag-Cu | 40/50 |
| 0.68 | 5 | 28 | 58 | 1.0Ag-Cu | 40/50 |
| 0.82 | 5 | 30 | 58 | 1.0Ag-Cu | 40/50 |
| 1 | 5 | 33 | 58 | 1.0Ag-Cu | 40/50 |
| 400VDC | |||||
| 0.1 | 3 | 20 | 21 | 1.0Ag-Cu | 40/50 |
| 0.22 | 3 | 23 | 26 | 1.0Ag-Cu | 40/50 |
| 0.33 | 3 | 23 | 36 | 1.0Ag-Cu | 40/50 |
| 0.47 | 3 | 25 | 41 | 1.0Ag-Cu | 40/50 |
| 1 | 5 | 30 | 58 | 1.0Ag-Cu | 60/70 |
| 1.2 | 5 | 33 | 58 | 1.0Ag-Cu | 60/70 |
| 1.5 | 5 | 37 | 58 | 1.0Ag-Cu | 60/70 |
| 1.8 | 5 | 41 | 58 | 1.0Ag-Cu | 60/70 |
| 2 | 5 | 42 | 58 | 1.0Ag-Cu | 60/70 |
| 2.2 | 5 | 44 | 58 | 1.0Ag-Cu | 60/70 |
| 2.5 | 5 | 40 | 58 | 1.0Ag-Cu | 60/70 |
| 2.7 | 5 | 43 | 58 | 1.0Ag-Cu | 60/70 |
| 3 | 5 | 46 | 58 | 1.0Ag-Cu | 60/70 |
| 3.3 | 5 | 46 | 58 | 1.0Ag-Cu | 60/70 |
| 250VDC | |||||
| 3.9 | 5 | 34 | 58 | 1.0Ag-Cu | 60/70 |
| 4.3 | 5 | 38 | 58 | 1.0Ag-Cu | 60/70 |
| 4.7 | 5 | 40 | 58 | 1.0Ag-Cu | 60/70 |
| 5.6 | 5 | 44 | 58 | 1.0Ag-Cu | 60/70 |
| 100VDC | |||||
| 6.8 | 5 | 41 | 58 | 1.0Ag-Cu | 60/70 |
| 8.2 | 5 | 44 | 58 | 1.0Ag-Cu | 60/70 |
Payment
We accept only Paypal payment.
After completing a "Buy It Now" purchase, you can complete the payment thru PAYPAL immediately.
Shipping
Item will be shipped within 48 hours after full payment is received.(Except Public Holiday)
Standard shipping: We will ship your package via FedEx with freight charge. Tracking Number Will Be Available.Transportation time about 7 to 10 days.
Customer Service
Our commitment to you is to answer your e-mail within 24 hrs, weekend within 48 hrs. Send us an email with any questions or concerns you may have.For more information, please send emails to us or please contact us via ebay message.
Important Notice
If you need other quantities of different values, please do not hesitate to email us.
We are glad to serve you, Thank you very much
WEET Capacitors Best Audio Capacitors for OEM Speaker Amplifier Manufacturer and Crossover Assembly etc.
Making quality music capacitors is our only business.
Why Choose WEE Technology
40 Years Experience in Audio Capacitors Superior Quality and Competitive Price
Small MOQ and OEM Customized Service One-on-one Dedicated Sales Service
