SF-380D Mobile Impact Crusher is suitable for a wide range of medium-hard materials, making it ideal for handling construction and demolition debris such as concrete, asphalt, bricks, and limestone. Key application areas include:
Urban Construction Waste Recycling
The unit efficiently processes reinforced concrete, bricks, and rubble generated from demolition projects, converting them into reusable aggregate for infrastructure works.
Road Maintenance and Asphalt Recycling
It can crush asphalt pavement and old road materials, supporting material reuse and cost reduction on road projects.
Auxiliary Crushing in Mining Sites
In quarries or mining operations that require temporary or mobile crushing capacity, the SF-380D serves as a versatile and efficient secondary crusher.
Short-Term or Remote Construction Projects
For job sites with space constraints or limited project durations, the SF-380D offers fast setup and high mobility, providing an efficient solution for temporary crushing needs.
With its compact structure, flexible mobility, and user-friendly operation, the SF-380D can operate as a standalone unit or in combination with screening equipment. It adapts easily to various crushing demands and is an excellent choice for small to medium-sized recycling or construction projects.
Project | Name | SF-380D |
Feed section | Feeding capacity (t/h) | 230 |
Hopper volume (m³) | 5 | |
Power (kw) | 4.5×2 | |
Feeder size (length x width) (mm) | 3960×1280 | |
Feeding height (mm) | 3850 | |
Crusher | Crusher model | 1214 |
Feed inlet size (length x width) (mm) | 1380×970 | |
Maximum feed particle size (mm) | 600 | |
Adjustment range of discharge port (mm) | 300-500\0-150 | |
Crusher weight (t) | 18 | |
Crusher power (kw) | 220 | |
Main belt | Length x Width (mm) | 11000×1600 |
Unloading height (mm) | 3250 | |
Power (kw) | 9.5×2 | |
Belt for finished materials | Length x Width (mm) | 5200×1350 |
Unloading height (mm) | 2860 | |
Power (kw) | 7.2×2 | |
Return material hanging sieve | Length x Width (mm) | 4600×2160 |
Power (kw) | 3.7×2 | |
Number of sieve layers (layers) | 1 | |
Screen size (mm) | 4000×1540 | |
Transition belt | Length x Width (mm) | 1750×970 |
Power (kw) | 3 | |
Return conveyer belt | Length x Width (mm) | 7000×770 |
Power (kw) | 5.5 | |
De-ironing separator | Length x Width (mm) | 2100×910 |
Power (kw) | 3 | |
Complete machine | Track chassis model | LDZ55-3657 |
Engine power (kw) | 100 | |
Whole machine weight (t) | 51 | |
Machine processing capacity (t/h) | 150-180 | |
Total power of crushing work (kw) | 282.9 | |
Working dimensions (length, width, height/mm) | 17652×3500×4000 | |
Transportation dimensions (length, width, height/mm) | 17652×3500×3900 |
