HFU-5 Fully Hydraulic Underground Core Drilling Rig Private Label Manufacturing Innovation

Category

Machinery

Sub-Category

Drilling Equipment For Mining

Completed orders

0

Price

$65000.00

Delivery Cost

$0.00

Minimum Order

1 pieces

Location

E-commerce Industrial Park, Dongqing Street, High-tech Zone, Zhengzhou, Henan, China

Typeunderground drilling rig
Power TypeElectric
UseCoal
Voltage220V,440V
Drilling Diameter1500mm
Drilling Depth240-800m
Place of OriginHenan, China
Weight5000kg
Warranty1 Year
Core ComponentsGear, Bearing, Engine
Key Selling PointsEasy to Operate
Brand NameHF
Dimension(L*W*H)3730*1200*1810mm
Machinery Test ReportProvided
Video outgoing-inspectionProvided
Mobilitymoblie
After-sales Service ProvidedNo after-sales service
Rotary torque1600N.m
Lifting force140kN
Feeding force70kN
Diesel engineCummins 6BT5.9-C130 97KW
Feeding stroke1800mm
Mud pump single pump max. Flow rate160L/min 2.5Mpa
Mud pump max. pressure10Mpa 44L/min
Drilling angleUp15°~down90° continuously adjustable
Main machine (L*W*H)3730*1200*1810mm
Packaging DetailsStandard export packaging or according to customer requirements
PortQINGDAO/NINGBO/SHANGHAI PORT
Selling Units:Single item
Single package size:58X56X66 cm
Single gross weight:68.000 kg
Supply Ability20 Set/Sets per Month
