This is an aberration-absorbing Schmidt telescope designed to provide aberration-free imaging for visualization and photography over large fields of view. This optical system not only reduces more off-axis coma, but also results in a flat focal plane and field of view edge play of the usual astrophotographer quality.

True astrophotographic quality

Many optical designs claim that their telescopes have “astrophotographic” quality, but in fact only produce star points by curving the focal plane. This may be acceptable for visual observation, but when using the flat chip sensors of digital cameras, the stars are out of focus at the edges.

The optics provide a much flatter focal plane than a standard Schmidt-Cassegrain telescope and three times flatter than an ablative optic.

This ensures that you get sharp peripheral images through some of the largest CCDs available today -

chips.

The superior edge-to-edge performance of the

not only results in a more pleasantly moist star point, but also actually improves the separation and limiting magnification compared to telescopes of the same aperture.

STARBRIGHT XLT® Coatings With every surface of the

optics coated with XLT coatings, the EdgeHD optics provide you with large flux through the widest possible visual and photographic spectrum.

Optical Design: EdgeHD

Aperture: 356mm (14“)

Focal Length: 3910mm

Focal Ratio: F11

Eyepiece: 23mm (170x)

Stargazer: 9x50

Zenith Lens: 2” (with 1.25" adapter ring)

Highest Effective Magnification: 841x

Lowest Effective Magnification: 51x

Magnitude Limit: 15.3 mag

Resolution (Rayleigh's Limit): 0.39 arcseconds

Resolution (Dow limit): 0.33 arc second

Concentrating power: 2586x (relative to the human eye)

Field of view: 0.48 degrees (standard eyepieces)

Linear field of view: 8.53 meters/1000 yards

Auxiliary lens shading: 114 mm

Auxiliary lens shading ratio (diameter): 32%

Auxiliary lens shading ratio (area): 10%

Coating: StarBright XLT Coating

Tube length: 787 mm

Tube Weight: 20 kg
