20411RW One Piece Fittings

Product Introduction

HT Hydraulics Since 1987 Hydraulic Hose Fitting -One Piece Fittings

Metric Female 24° Cone O-ring L.T.ISO 12151-2-DIN3865

H20411-TRW						HT Hydraulics Since 1987 Hydraulic Hose Fitting -One Piece Fittings
H20411-TRW						Metric Female 24° Cone O-ring L.T.ISO 12151-2-DIN3865
Part No.	Thread	HOSE BORE		TUBE O.D	DIMENSIONS
Part No.	Thread	DN	DASH	TUBE O.D	B		W
H20411-12-04TRW	M12X1.5	6	04	6	22		17
H20411-14-04TRW	M14X1.5	6	04	8	23.5		17
H20411-16-04TRW	M16X1.5	6	04	10	20.5		19
H20411-16-05TRW	M16X1.5	8	05	10	25.5		19
H20411-18-05TRW	M18X1.5	8	05	12	23.5		22
H20411-18-06TRW	M18X1.5	10	06	12	26.5		22
H20411-22-08TRW	M22X1.5	13	08	15	28.5		27
H20411-26-08TRW	M26X1.5	13	08	18	30		32
H20411-26-10TRW	M26X1.5	16	10	18	32		32
H20411-30-10TRW	M30X2	16	10	22	32.5		36
H20411-30-12TRW	M30X2	19	12	22	33.5		36
H20411-36-12TRW	M36X2	19	12	28	35		41
H20411-36-16TRW	M36X2	25	16	28	36		41
H20411-45-16TRW	M45X2	25	16	35	34		50
H20411-45-20TRW	M45X2	32	20	35	35		50
H20411-52-20TRW	M52X2	32	20	42	38		60
H20411-52-24TRW	M52X2	38	20	42	38		60

Our One-Piece Hose Fittings&Unified Hose Fittings Are Distinguished By The Following Features:

High Precision Manufacturing: Utilizing Advanced CNC Machines And Hot Forging Techniques To Ensure Accurate Dimensions And Superior Strength.

Durable Materials: Made From High-Quality Stainless Steel And Other Robust Materials To Withstand Extreme Pressures And Harsh Environments.

Leak-Free Design: Engineered To Provide A Secure And Leak-Free Connection, Enhancing The Safety And Efficiency Of Hydraulic Systems.

Wide Range Of Sizes: Available In A Variety Of Sizes And Configurations To Meet The Specific Needs Of Different Hydraulic Applications.
